| Model No. | KY-F-HX-001 |
| System Voltage | DC24V |
| Lithium Battery | 25.6V/42AH |
| Solar Panel | 180W/36V |
| Model No. | KY-F-HX-002 |
| System Voltage | DC24V |
| Lithium Battery | 25.6V/48AH |
| Solar Panel | 240W/36V |
| Model No. | KY-F-HX-003 |
| System Voltage | DC24V |
| Lithium Battery | 25.6V/60AH |
| Solar Panel | 360W/36V |
| Model No. | KY-F-HX-004 |
| System Voltage | DC24V |
| Lithium Battery | 25.6V/84AH |
| Solar Panel | 360W/36V |
Design of bat wing light distribution, making lighting more even.
Intelligent control system, providing lighting as required and reducing power consumption for the whole light.
Single crystal silicon solar panel with highest photoelectric conversion rate.
| Model No. | KY-F-HX-001 | KY-F-HX-002 | KY-F-HX-003 | |
| Rated Power | 60W | 120W | 180W | |
| Input voltage | DC12V | DC24V | ||
| Lithium Battery | 12.8V/60AH | 25.6V/60AH | 25.6V/84AH | |
| Solar Panel | 180W/18V | 240W/36V | 360W/36V | |
| Light Source | 3030/5050 | |||
| Light Distribution | Bat-Wing light distribution(150°x75°) | |||
| Light Efficiency | ≥130LM/W | |||
| Color Temperature | 3000K/4000K/5700K/6500K | |||
| CRI | ≥Ra70 | |||
| IP | IP66 | |||
| IK | IK08 | |||
| Working Temperature | -40℃~+60℃ | |||
| Lamp Weight | 4.6kg | 7.6kg | ||
| LED Lifespan | ＞50000H | |||
| Controller | 15A | 20A | ||
| Mount Diameter | φ60mm | |||
| Lamp Dimension | 645×295×144mm | 775×320×150mm | ||
| Packing Dimension | 695×350×200mm （1pc/CTN） | |||
| Suggested Mount Height | 8m~10m | 10m~12m | ||
