| Model No. | KY-D-HX-001 |
| System Voltage | AC100V～305V |
| Rated current | 1.7A |
| Light Efficiency | ≥130LM/W |
| Model No. | KY-D-HX-002 |
| System Voltage | AC100V～305V |
| Rated current | 1.88A |
| Light Efficiency | ≥130LM/W |
| Model No. | KY-D-HX-003 |
| System Voltage | AC100V～305V |
| Rated current | 2.25A |
| Light Efficiency | ≥130LM/W |
| Model No. | KY-D-HX-004 |
| System Voltage | AC100V～305V |
| Rated current | 2.8A |
| Light Efficiency | ≥130LM/W |
| Model No. | KY-D-HX-005 |
| System Voltage | AC100V～305V |
| Rated current | 3.38A |
| Light Efficiency | ≥130LM/W |
Patented lens and bat wing light distribution, making lighting more even.
Intelligent control system, providing lighting as required and reducing power consumption for the whole light.
Both light poles and foundation screws are made of Q235 steel, and both light poles and foundation concretes can meet the strength requirements of no deformation or damage under Level-13 typhoon limit.
| Model No. | KY-D-HX-001 | KY-D-HX-002 | KY-D-HX-003 | KY-D-HX-004 | KY-D-HX-005 | |
| Rated Power | 80W | 120W | 150W | 180W | 240W | |
| System Voltage | AC100V～305V | AC100V～305V | ||||
| Rated current | 1.7A | 2.25A | 2.8A | 3.38A | 4.5A | |
| Light Source | 3030/5050 | |||||
| Light Distribution | Bat-Wing light distribution(150°*75°） | |||||
| Light Efficiency | ≥130LM/W | |||||
| Color Temperature | 3000K/4000K/5700K/6500K | |||||
| CRI | ≥Ra70 | |||||
| IP | IP66 | |||||
| IK | IK08 | |||||
| Working Temperature | -10℃～+60℃ | |||||
| Lamp Weight | 4.6kg | 7.6kg | 8.3kg | |||
| LED Lifespan | ＞50000H | |||||
| Driver Type | Meanwell | |||||
| Mount Diamete | φ60mm | |||||
| Lamp Dimension | 645×295×144mm | 775×320×150mm | ||||
| Packing Dimension | 695×350×200mm (1pc/CTN) | 830×370×210mm (1pc/CTN) | ||||
| Suggested Mount Height | 8m～10m | 10m～12m | 12m～15m | |||
