| Model No. | KY-F-XY-001 |
| System Voltage | DC12V/24V |
| Lithium Battery | 12.8V/42AH |
| Solar Panel | Monocrystalline 18V/120W |
| Model No. | KY-F-XY-002 |
| System Voltage | DC24V |
| Lithium Battery | 12.8V/60AH |
| Solar Panel | Monocrystalline 18V/180W |
| Model No. | KY-F-XY-003 |
| System Voltage | DC24V |
| Lithium Battery | 25.6V/42AH |
| Solar Panel | Monocrystalline 36V/180W |
surface electrostatic spraying treatment with strong resistance to corrosion; design of bat airfoil light distribution, providing even light distribution; excellent chips adopted, durable and less light attenuation.
Intelligent control system, providing lighting as required and reducing power consumption for the whole light.
Built-in 32650 lithium iron phosphate battery, up to 2,000 times of deep cycles, safe and reliable, no fire and no explosion.
| Model No. | KY-F-XY-001 | KY-F-XY-002 | KY-F-XY-003 |
| Rated Power | 40W | 60W | 80W |
| System Voltage | DC12V/24V | DC12V/24V | DC24V |
| Lithium Battery | 12.8V/42AH | 12.8V/60AH | 25.6V/42AH |
| Solar Panel | Monocrystalline 18V/120W | Monocrystalline 18V/180W | Monocrystalline 36V/180W |
| Light Source | 3030/5050/7070 | ||
| Light Distribution | Bat-Wing light distribution（150°x65°） | ||
| Light Efficiency | ≥150LM/W | ||
| Color Temperature | 3000K/4000K/5000K/5700K | ||
| CRI | ≥Ra70 | ||
| IP | IP65 | ||
| IK | IK08 | ||
| Working Temperature | -10℃~+60℃ | ||
| Working Humidity | 10%~90% | ||
| LED Lifespan | ＞50000H | ||
| Controller | 10A | 15A | 15A |
| Mount Diameter | φ60mm | ||
| Lamp Dimension | 570 x 330 x 80 mm | ||
| Suggested Mount Height | 6~7m | 8~9m | 9~10m |
| Lamp Weight | 3.4kg | ||
| Packing Dimension | 630 x 390 x 140 mm | ||
